JH-1WY14G30-F2A
LEDGUHON
Availability: | |
---|---|
Quantity: | |
Product Feature:
★Adopt well-known vender’s chip package
★99.99% gold wire welding
★Good bright spots and High bright
Product Use:
★Stage Light,Decorative Light
★Fountain Light,Aquarium Light,etc
Remarks:
★This kind led is high power 2W white+yellow led, each 1W
★White,can make 6000-8000K CCT and yellow can make 585-595nm
★If need change the white CCT,please tell us at first
★This led use 4pins copper frame to make,2 colors into 1 led,when use it,please make good heat sink
★Usually don't have the 20mm star base pcb for this kind led,if need,please ask at first
★The 2 colors chip place can exchanged, based on your demands
★When use the led,please make sure the led working temperature is not very bad,suggest in dry environment
★The PCB temperature is about 40~60℃ when the led working
★If possible, you can use cool fan under the pcb
★The reflow soldering temperature is 260℃/3s MAX;if use heating platform by hand,please use 360℃/3s;it is very important,please don't pass this limit
★When take the led,please don't press the led top lens heavily,this way will damage the led
★CE ROHS approved
