1W 3W Green Color High Power Led Chip

Product Feature:

★High bright and good heat sink

★Adopt well-known vender’s chip package

★99.99% gold wire welding

Product Use:

★Stage Light,Wall Wash Light,Spot Light

★Decorative Light,Aquarium Light,etc

Remarks:

★Green led chip wavelength normal is 520-525nm,some times can be 515-520nm,based on the buyer demands

★Make high power 1w and 3w green led,if need make another power,also can make,please ask us at first

★Green color chip voltage usually a little lower than blue chip,but higher than red and yellow

★The high power led normal light angle is 140deg

★Can custom 60deg and 90deg,price is higher than 140deg,if you need,please ask at first

★Suugest 1w green led,current below 350mA,Voltage based on actual led, if 2.8-3.0V,please use 2.8-3.0V,if 3.0-3.4V can use below this value

★3w green led,current below 700mA,Voltage based on actual led, if 2.8-3.0V,please use 2.8-3.0V,if 3.0-3.6V can use below this value

★Usually use Taiwan Eplileds chip to make the green color led;other brands is Sanan or China mainland brands,based on your demands

★Specail green wavelength also can make,500-510nm or 530-540nm

★CE,RoHS approved

★ISO 9001 approved
