3w High Power IR 740nm Led

Product Feature:

★Adopt well-known vender’s chip package

★99.99% gold wire welding

★Good heat sink and High bright

Product Use:

★Monitoring, Infrared equipment,etc

Remarks:

★This kind is 740nm IR led,as use 700mA,call it as 3W

★Real power use voltage*current is not 3W,please don't use this power to match the 3W we said

★If need real power reach 3W,then need connect more chips to get the higher voltage or current,please tell us at first

★5nm as a range,can make 735-740nm or 740-745nm,normal is 740-745nm

★This kind light angle is 140deg, so will pack 1000pcs/reel;if 60deg, will pack 800pcs/reel

★The reflow soldering max temperature is 260℃,max time is 3 seconds,please note it

★When soldering the led, the led top lens will be more soft,please be careful,don't press the led lens

★Use the copper frame and gold wires to make the led,the led heat sink ability is well

★Need soldering the led onto the pcb,pcb size need enought,please use the fan to make the heat sink,if you can

★CE ROHS approved,other certificate based on your demands
