JH-3IR14G42-T3A-M810
LEDGUHON
| Quantity: | |
|---|---|
Product Feature:
★Adopt well-known vender’s chip package
★99.99% gold wire welding
★Good heat sink and High light power
Product Use:
★Monitoring, Infrared equipment,etc
Remarks:
★The 810nm IR led,our range is 800-810nm;recently don't have 810-815nm
★Voltage of this kind is 1.6-2.0V,have a range;current is 700mA, call it as 3W IR led
★If use 350mA, call it as 1W;some people use like this,this kind suit
★The light angle,normal is 140deg,real test is about 120-140deg
★If want make 60deg light angle,please ask at first
★After receive the led,please confirm the pack is well,if leaked,please bake the led at 60℃/12hours,then use the led
★When use the led,please make the Esd Measures
★Just see by eye,the led chip is a little red color, as the IR color we can't see by eye,the red color is from the chip
★Normal pack,1000pcs/reel;if need by tube pack,also can do it,please tell at first
★High power IR led,usually use T3A copper frame to make, frame color is black color
★ISO 9001 approved
