LED Light Chip LED Opto Blue 460nm 3535 Chip LED High Power LED 1W 3 Watt Blue

1W 3W 3535 LED High Power LED Chip for Aquarium 470nm Blue LED Chip LED Parts Blue LED Diode
  • LEDGUHON

Availability:
Quantity:
Product Description

LED 460nm Blue 1W 3W High Power LED Bead SMD 3535 Chip LED High Power LED 460nm design for high thermal stability and reliability. The luminous Angle of the product can be selected as 30 degrees, 60 degrees, 90 degrees and 120 degrees, according to different application scenarios. In addition, the wavelength of the product can be customized according to the needs of customers, common wavelengths are 450nm, 460nm, 470nm, etc. The product has a power of 1/3W and can provide stable optical output. The product is widely used in teeth whitening kit, emergency LED lights, LED grow bar, LED police lights, etc.

JH-3535B12G45-T8A-1 JH-3535B6G45-T8A-1 JH-3535B12S26-T7A-1
Dimension

JH-3535B12G45-T8A-2JH-3535B6G45-T8A-2


Notes:

1. All dimensions are in millimeters.

2. Tolerance is ±0.1mm unless otherwise noted.

3. It can also be made to 3030/5050 specifications.

Products Description
Wavelength
Power
Voltage
Current
Luminous Flux
450-460nm
1-2W
3.0-3.4V
350-700mA
30-60LM
460-470nm
1-2W
3.0-3.4V
350-700mA
30-60LM
470-480nm
1-2W
3.0-3.4V
350-700mA
30-60LM
Product application
Product application

LED emergency light bar, blue LED grow light, blue LED strobe lights, medical beauty & care, etc


If you have more questions, please contact us.
